1658542-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
D-Sub Contacts SOCKET CONT DUPL PLT STRIP HD-
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.30184
≥100 USD $0.300256
≥500 USD $0.29392
≥1000 USD $0.25124
≥3000 USD $0.22609
Inventory: 36406
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness Flash
Length 13.46mm
Technical
Cable Entry-Max 0.068 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Max Current Rating 3.1A
ELV Compliant
Wire Gauge 18-22 AWG
Contact Gender FEMALE
Contact Finish Gold
Depth 2.29mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Additional Feature TERMINATION: TIN OVER NICKEL
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPLIMITE HDP-20
Published 2008
Packaging Tape & Reel (TR)
Physical
Material Bronze
Mount Cable
Contact Plating Gold, Nickel, Tin
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 7 Weeks
