1658538-3 image
Favorite
1658538-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description CONN SOCKET 24-28AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.19096
≥100 USD $0.19008
≥500 USD $0.187792
≥1000 USD $0.173624
≥3000 USD $0.142701
Inventory: 42954
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Contact Finish Thickness Flash
Length 14.09mm
Height 2.15mm

Technical

Max Supply Voltage (AC) 250V
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter -1.02 mm
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 28 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Max Current Rating 1.2A
ELV Compliant
Wire Gauge 24-28 AWG
Contact Gender Female
Contact Finish Gold
Depth 2.15mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPLIMITE HDP-20
Published 2005
Packaging Tape & Reel (TR)

Physical

Material Bronze
Mount Cable
Contact Plating Gold, Tin
Contact Material Phosphor Bronze

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 7 Weeks
