1658538-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SOCKET 24-28AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.36168
≥100 USD $0.301048
≥500 USD $0.224294
≥1000 USD $0.200209
≥3000 USD $0.186305
Inventory: 3384
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Contact Finish Thickness Flash
Length 14.09mm
Height 2.15mm
Technical
Pin or Socket Socket
Insulation Diameter 1.02 mm
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 28 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Max Current Rating 1.2A
ELV Compliant
Wire Gauge 24-28 AWG
Contact Gender Female
Contact Finish Gold
Depth 2.15mm
Shielding Unshielded
Orientation Straight
HTS Code 8536.90.40.00
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPLIMITE HDP-20
Published 2007
Packaging Bulk
Physical
Material Bronze
Mount Cable
Contact Plating Tin
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 months ago)
Factory Lead Time 13 Weeks
