164161-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN PIN 16-18AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9768
≥1 USD $0.9768
≥10 USD $0.9152
≥100 USD $0.880704
≥500 USD $0.872256
≥1000 USD $0.78716
≥3000 USD $0.761622
Inventory: 13300
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Material Brass
Contact Plating Nickel
Mount Cable
Technical
Packaging Cut Tape (CT)
Published 2004
Series Multimate III+
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Type Stamped
Number of Positions 28
Gender Male
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 2.54mm
Orientation Straight
Shielding Unshielded
Depth 3.7mm
Current Rating 13A
Contact Finish Gold
Wire Gauge 16-18 AWG
ELV Compliant
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 16 AWG
Wire/Cable Gauge 18 AWG
Contact Termination Crimp
Test Current 13A
Insulation Diameter -2.49 mm
Pin or Socket Pin
Assembly Item Name CONTACT
Cable Entry-Min 0.08 inch
Make First / Break Last Yes
Dimensions
Height 3mm
Length 29.4mm
Contact Finish Thickness 31.5μin 0.80μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Not Applicable
