163084-1
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
Pin & Socket Connectors 062 SOC.ASS. TYP3+
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.1616
≥1 USD $1.1616
≥10 USD $1.08416
≥100 USD $1.044032
≥500 USD $1.034
≥1000 USD $0.933152
≥3000 USD $0.902845
Inventory: 4918
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Plating Thickness 2μm
Contact Finish Thickness 78.7μin 2.00μm
Length 21mm
Technical
Cable Entry-Min 0.079 inch
Cable Entry-Max 0.098 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Wire/Cable Diameter 2.5 mm
Insulation Diameter 2.49 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 15 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 18 AWG
ELV Compliant
Wire Gauge 16-18 AWG
Contact Gender Female
Contact Finish Tin
Current Rating 13A
Depth 3.7mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multimate III+
Published 1995
Packaging Bulk
Physical
Number of Pins 1
Package / Case 062
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 29 Weeks
