1544187-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Leadframe
Description
Connector Accessories Leadframes
PDF
/
Buying Options
Total Price: USD $0.04
Unit Price: USD $0.037193
≥1 USD $0.037193
≥200 USD $0.014841
≥500 USD $0.014345
≥1000 USD $0.0141
Inventory: 8909
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Frame Thickness 0.010 0.25mm
Board Thickness 0.025 0.64mm
PCB Thickness 630μm
Technical
Clip Type F1
Clip Length 0.049 1.25mm
Pin Length 0.213 5.41mm
Frame Width 0.713 18.10mm
Clip Style DIL
ELV Compliant
Lead Length 5.4102mm
Contact Finish Tin
Reach Compliance Code unknown
Orientation Straight
Pitch 0.100 2.54mm
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2009
Packaging Reel
Physical
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 16 Weeks
