DRC3P48D400R2
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Relays / Contactors (Solid State)
Description
Contactor,Three-Phase,480VAC,7.6A,24VAC/VDC Cont,NO Aux.,RN 2L,DRC Series
PDF
/
Inventory: 1893
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 45.31mm
Length 45.31mm
Height 86.71mm
Technical
Min Supply Voltage (AC) 48V
Coil Voltage (AC) 24V
Max Supply Voltage (AC) 530V
Coil Voltage (DC) 24V
Voltage - Load 48V~530V
Relay Type Contactor
Throw Configuration 3P, 3PST
Voltage - Input 18V~30VAC/DC
Max Current Rating 7.6A
Max Voltage Rating (AC) 530V
Min Supply Voltage 48V
Max Supply Voltage 530V
Circuit 3PST-NO (3 Form A)
Operating Supply Voltage 530V
Output Type AC
Voltage - Rated AC 480V
Termination Style Screw Terminal
Depth 96.02mm
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Solicon DRC
Published 2014
Packaging Bulk
Physical
Number of Pins 7
Package / Case Module
Mounting Type Chassis Mount, DIN Rail
Mount DIN Rail
Supply Chain
Factory Lead Time 6 Weeks
