DP4RSC60D60B
RoHS
RoHS compliant
RoHS compliantPackage Hockey Puck
Category Relays / Contactors (Solid State)
Description
RoHS Compliant Active Contactor Screw Solid State Relay Contactor 5mOhm 80C 3PST SPST 73.5mm
PDF
/
Buying Options
Total Price: USD $289.46
Unit Price: USD $289.460655
≥1 USD $289.460655
≥10 USD $112.018683
≥100 USD $108.080868
≥500 USD $106.136268
Inventory: 1371
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 104mm
Height 20mm
Technical
Min Supply Voltage (DC) 1V
Isolation Voltage 2.5kV
Max Supply Voltage (DC) 48V
Load Current 60A
Voltage - Load 1V~48V
Relay Type Contactor
Throw Configuration 3PST, SPST
Nominal Supply Current 20mA
Voltage - Input 4.5V~15VDC
Circuit SPST-NO (1 Form A)
Operating Supply Voltage 15V
Output Type DC
Termination Style Screw Terminal
Depth 73.5mm
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Resistance 5mOhm
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DP
Published 2011
Packaging Bulk
Physical
Number of Pins 4
Package / Case Hockey Puck
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Factory Lead Time 6 Weeks
