RN2A48D50 image
Favorite
RN2A48D50 image
Favorite
RoHS
/
Package /
Category Relays / Contactors (Solid State)
Description CARLO GAVAZZI RN2A48D50Solid State Relay, DPST, 50 A, DIN Rail, Screw, 42 VAC, 530 VAC
PDF
/
Inventory: 5558
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 89.9922mm
Length 119.9896mm

Technical

Min Supply Voltage (AC) 42V
Control Voltage 5V
Output Circuit Type SCR
Control Current 0.009A
Max Supply Voltage (AC) 530V
Load Current 50A
Overall Height 103mm
Max Input Current 9mA
Contact Current Rating 50A
Max Output Voltage 530V
Input Type DC
Throw Configuration DPST
Number of Poles 2
Output Current 12mA
Max Voltage Rating (AC) 530V
Operating Supply Voltage 530V
Max Output Current 50A
Approval Agency CE, CSA, UL
Voltage - Rated AC 530V
Current Rating 50A
Depth 2.9972mm
Subcategory Solid State Relays
Min Operating Temperature -20°C
Max Operating Temperature 70°C
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Published 2002

Physical

Number of Pins 4
Mount DIN Rail
