A02501
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Configurable Switch Components - Contact Block
Description
CONTACT BLOCK SPST-NO 16A 250V
PDF
/
Buying Options
Total Price: USD $7.04
Unit Price: USD $7.038695
≥1 USD $7.038695
≥10 USD $6.640277
≥100 USD $6.264422
≥500 USD $5.909823
≥1000 USD $5.575308
Inventory: 1465
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 21mm
Length 33.5mm
Height 27mm
Technical
Requires Switch Body
Compatible Series Apem, A02 (First Block)
Switch Action MOMENTARY
Contact Function ON-OFF-ON
Contact Rating @ Voltage 16A @ 250VAC
Contact Timing DOUBLE BREAK
Illumination Type Non-Illuminated
Contact Current Rating 16A
Switch Type ROTARY SWITCH
Throw Configuration SPST
Number of Poles 1
Electrical Life 50000 Cycle(s)
Insulation Resistance 50MOhm
Contact Resistance 10mOhm
Circuit SPST-NO
Actuator Type ROTARY
Voltage - Rated AC 250V
Termination Style Screw Terminal
Current Rating 16A
Depth 21mm
Additional Feature SHORT LEVER, SQUARE OPERATOR
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Number of Positions 3
Termination Screw
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series A02
Physical
Insulation Material POLYBUTYLENE TEREPHTHALATE
Mounting Feature PANEL MOUNT
Surface Mount NO
Contact Material Silver
