A165S-A2A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Configurable Switch Components - Body
Description
Momentary A165S 2 PANEL MOUNT Configurable Switch Body 18mm 5A 30V 3A@30VDC
PDF
/
Buying Options
Total Price: USD $13.93
Unit Price: USD $13.927243
≥1 USD $13.927243
≥200 USD $5.390767
≥500 USD $5.200397
≥1000 USD $5.107181
Inventory: 3827
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Surface Mount NO
Mounting Feature PANEL MOUNT
Number of Pins 2
Technical
Published 2006
Series A165S
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Momentary
Number of Positions 2
Reach Compliance Code unknown
Body Length or Diameter 18mm
Operating Temperature (Max) 55°C
Body Breadth 15.8 mm
Actuator Type Selector
Operating Temperature (Min) -10°C
Switch Function DPDT
Panel Cutout Dimensions 16mm (Round)
Contact Current(DC)-Max 3A
Sealing IP65
Contact Voltage(DC)-Max 30V
Electrical Life 100000 Cycle(s)
Illumination Non-Illuminated
Contact Current(AC)-Max 5A
Contact (DC) Max Rating R Load 3A@30VDC
Number of Switch Sections 1
Switch Action LATCHED
Compatible Series Omron, A165S
Requires Contact Block(s)
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
