7448640401
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 6.8MH 800MA 2LN TH
PDF
/
Inventory: 4008
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height (Max) 0.701 17.80mm
Width 21.209mm
Length 21.209mm
Height 17.8054mm
Technical
Inductance @ Frequency 6.8mH @ 10kHz
Current Rating (Max) 800mA
DC Resistance (DCR) (Max) 480mOhm Typ
Number of Lines 2
Filter Type Power Line
Max DC Current 800mA
Current 800mA
Inductance 6.8 mH
Lead Pitch 13mm
Voltage - Rated AC 250V
Current Rating 800mA
Depth 21.2mm
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 480mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 10%
Size / Dimension 0.835Lx0.835W 21.20mmx21.20mm
Series WE-FC
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Core Material Ferrite
Number of Pins 4
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Radial, Through Hole
Supply Chain
Factory Lead Time 18 Weeks
