744822301
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 1MH 3A 2LN TH
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.40635
≥1 USD $2.40635
≥10 USD $1.9741
≥100 USD $1.91235
≥500 USD $1.8506
≥1000 USD $1.78885
Inventory: 1121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series WE-CMB
Size / Dimension 0.689Lx0.512W 17.50mmx13.00mm
Tolerance 30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Resistance 35mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Depth 13mm
Current Rating 3A
Voltage - Rated AC 250V
Lead Pitch 7.7mm
Inductance 1 mH
Test Frequency 10kHz
Current 3A
Max DC Current 3A
Filter Type Power Line
Inductance Tolerance 30%
Series Resistance 35mOhm
Number of Lines 2
DC Resistance (DCR) (Max) 35mOhm
Current Rating (Max) 3A
Inductance @ Frequency 1mH @ 10kHz
Dimensions
Height 22mm
Length 17.5mm
Width 13mm
Height (Max) 0.866 22.00mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
