7446823003
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 2.7MH 3A 2LN TH
PDF
/
Buying Options
Total Price: USD $4.76
Unit Price: USD $4.761053
≥1 USD $4.761053
≥10 USD $4.49156
≥100 USD $4.237317
≥500 USD $3.997469
≥1000 USD $3.771196
Inventory: 1133
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Horizontal, 4 PC Pin
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-LF
Size / Dimension 1.122Lx1.122W 28.50mmx28.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Resistance 60mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating 3A
Voltage - Rated AC 250V
Inductance 2.7 mH
Current 3A
Max DC Current 3A
Filter Type Power Line
Inductance Tolerance 30%
Number of Lines 2
DC Resistance (DCR) (Max) 60mOhm
Current Rating (Max) 3A
Inductance @ Frequency 2.7mH @ 10kHz
Dimensions
Height 16.9926mm
Length 28.4988mm
Width 28.4988mm
Height (Max) 0.669 17.00mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
