7446722004
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 4.2MH 1.9A 2LN TH
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1139
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Horizontal, 4 PC Pin
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-LF
Size / Dimension 0.906Lx0.906W 23.00mmx23.00mm
Tolerance 30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Resistance 120mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating 1.9A
Voltage - Rated AC 250V
Inductance 4.2 mH
Test Frequency 50Hz
Current 1.9A
Max DC Current 1.9A
Filter Type Power Line
Inductance Tolerance 30%
Number of Lines 2
DC Resistance (DCR) (Max) 120mOhm
Current Rating (Max) 1.9A
Inductance @ Frequency 4.2mH @ 10kHz
Dimensions
Height 14.5034mm
Length 23.0124mm
Width 23.0124mm
Height (Max) 0.571 14.50mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
