744230121 image
Favorite
744230121 image
Favorite
RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description CMC 450MA 2LN 120 OHM SMD
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.51585
≥1 USD $0.51585
≥10 USD $0.4237
≥100 USD $0.4104
≥500 USD $0.3971
≥1000 USD $0.3838
Inventory: 1339
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Height (Max) 0.047 1.20mm
Width 850μm
Length 1.6mm
Height 1.1938mm

Technical

Impedance @ Frequency 120Ohms @ 100MHz
Current Rating (Max) 450mA
DC Resistance (DCR) (Max) 175mOhm
Number of Lines 2
Filter Type Signal Line
Max DC Current 450mA
Current 450mA
Impedance 90Ohm
Test Frequency 100MHz
Voltage - Rated AC 50V
Frequency 1GHz
Current Rating 450mA
Depth 850μm
Voltage - Rated DC 50V
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Resistance 175mOhm
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 25%
Size / Dimension 0.063Lx0.033W 1.60mmx0.85mm
Series WE-CNSW
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C

Physical

Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 28 Weeks
