RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description CMC 1MH 800MA 2LN 6 KOHM SMD
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 37817
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4
Weight 500.992773mg
Core Material Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-SL2
Size / Dimension 0.362Lx0.236W 9.20mmx6.00mm
Tolerance 50%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 310mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Voltage - Rated 80V
Voltage - Rated DC 80V
Depth 6mm
Current Rating 800mA
Inductance 1 mH
Test Frequency 100kHz
Impedance 6kOhm
Current 800mA
Max DC Current 800mA
Filter Type Power, Signal Line
Inductance Tolerance 50%
Series Resistance 310mOhm
Number of Lines 2
DC Resistance (DCR) (Max) 310mOhm
Current Rating (Max) 800mA
Impedance @ Frequency 6kOhms @ 4MHz
Inductance @ Frequency 1mH @ 100kHz

Dimensions

Height 5mm
Length 9.2mm
Width 6mm
Height (Max) 0.209 5.30mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
