CMT-8113
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes 5.0mH 8.9A 0.022RDC Common Mode Inductor
PDF
/
Buying Options
Total Price: USD $6.15
Unit Price: USD $6.1512
≥1 USD $6.1512
≥10 USD $5.05648
≥100 USD $4.646752
≥500 USD $4.373424
≥1000 USD $4.168384
≥3000 USD $4.100061
Inventory: 50
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.500 38.10mm
Width 20.32mm
Length 36.83mm
Height 38.1mm
Technical
Inductance @ Frequency 5mH @ 1kHz
Current Rating (Max) 8.9A
DC Resistance (DCR) (Max) 22mOhm
Number of Lines 2
Filter Type Power Line
Max DC Current 8.9A
Current 8.9A
Inductance 5 mH
Approval Agency CSA, IEC, UL, VDE
Voltage - Rated AC 1500V 1.5kV
Current Rating 8.9A
Shielding Unshielded
Termination Radial
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature ESD
Size / Dimension 1.450Lx0.800W 36.83mmx20.32mm
Series CMT
Published 2014
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
