B82732W2601B030
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 47mH 10kHz 600mA 1.4Ohm DCR Thru-Hole Box
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.2792
≥1 USD $2.2792
≥10 USD $1.93864
≥100 USD $1.787104
≥500 USD $1.59676
≥1000 USD $1.330674
≥3000 USD $1.292685
Inventory: 1289
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.681 17.30mm
Technical
Inductance @ Frequency 47mH @ 10kHz
Current Rating (Max) 600mA
DC Resistance (DCR) (Max) 1.4Ohm Typ
Number of Lines 2
Filter Type Power Line
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.945Lx0.906W 24.00mmx23.00mm
Series B82732
Published 2013
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Package / Case Horizontal, 4 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
