B82731H2351A030
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 100mH 10kHz 350mA 4.5Ohm DCR Thru-Hole Box
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.25224
≥100 USD $1.153856
≥500 USD $1.03114
≥1000 USD $0.85932
≥3000 USD $0.834777
Inventory: 1223
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Package / Case Horizontal, 4 PC Pin
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series B82731
Size / Dimension 0.827Lx0.827W 21.00mmx21.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated AC 250V
Approval Agency ENEC, UR, VDE
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 4.5Ohm Typ
Current Rating (Max) 350mA
Inductance @ Frequency 100mH @ 10kHz
Dimensions
Height (Max) 0.610 15.50mm
Compliance
RoHS Status ROHS3 Compliant
