B82723A2602N001
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 1mH 100kHz 6A 22mOhm DCR Thru-Hole Box
PDF
/
Buying Options
Total Price: USD $2.18
Unit Price: USD $2.1824
≥1 USD $2.1824
≥10 USD $1.82336
≥100 USD $1.664608
≥500 USD $1.4267
≥1000 USD $1.39546
Inventory: 3803
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.661 16.80mm
Technical
Inductance @ Frequency 1mH @ 100kHz
Current Rating (Max) 6A
DC Resistance (DCR) (Max) 22mOhm Typ
Number of Lines 2
Filter Type Power Line
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.102Lx1.063W 28.00mmx27.00mm
Series B82723
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Package / Case Horizontal, 4 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
