B82722A2801N020
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 27mH 10kHz 800mA 600mOhm DCR Thru-Hole Box
PDF
/
Inventory: 2432
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Package / Case Horizontal, 4 PC Pin
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series B82722
Size / Dimension 0.894Lx0.878W 22.70mmx22.30mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated AC 250V
Approval Agency ENEC, UR, VDE
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 600mOhm Typ
Current Rating (Max) 800mA
Inductance @ Frequency 27mH @ 10kHz
Dimensions
Height (Max) 0.524 13.30mm
Compliance
RoHS Status ROHS3 Compliant
