B82720H0015A035
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters DATA LINE-CHOKE 2X68MH 0.3A
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.85856
≥100 USD $1.696992
≥500 USD $1.45464
≥1000 USD $1.333438
≥3000 USD $1.293046
Inventory: 2308
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Published 1999
Series B82720
Size / Dimension 0.512Lx0.374W 13.00mmx9.50mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 80V
Voltage - Rated AC 42V
Filter Type Signal Line
Number of Lines 2
DC Resistance (DCR) (Max) 3.3Ohm Typ
Current Rating (Max) 200mA
Inductance @ Frequency 68mH @ 10kHz
Dimensions
Height (Max) 0.551 14.00mm
Compliance
RoHS Status ROHS3 Compliant
