B82504WA16
RoHS
RoHS compliant
RoHS compliantPackage /
Category Filters / Common Mode Chokes
Description
CMC 120UH 16A 2LN CHAS MT
PDF
/
Inventory: 7659
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount
Technical
Packaging Tray
Series B82504
Size / Dimension 3.071Lx1.102W 78.00mmx28.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 600V
Voltage - Rated AC 500V
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 19mOhm Typ
Current Rating (Max) 16A
Inductance @ Frequency 120μH @ 100kHz
Dimensions
Height (Max) 1.457 37.00mm
Compliance
RoHS Status ROHS3 Compliant
