TCE0806S-120-2P

TDK Corporation
RoHS
/
Package 0302 (0806 Metric), 6 Lead
Category Filters / Common Mode Chokes
Description Common Mode Chokes / Filters 12ohms 1.0ohms 0.1A USB 3.0
PDF
/
Inventory: 5472
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 0.65mm
Length 0.85mm
Height 457.2μm

Technical

Rated Voltage 10V
Impedance @ Frequency 12Ohm @ 100MHz
DC Resistance (DCR) (Max) 1Ohm
Number of Lines 2
Filter Type Signal Line
Max DC Current 100mA
Current 100mA
Impedance 12Ohm
Insulation Resistance 1MOhm
Case Code (Imperial) 0302
Case Code (Metric) 0806
Number of Functions 2
Packing Method TAPE AND REEL
Voltage - Rated DC 10V
HTS Code 8504.50.80.00
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature ESD
Size / Dimension 0.033Lx0.026W 0.85mmx0.65mm
Series TCE
Published 2013
Packaging Cut Tape (CT)
Operating Temperature -25°C~85°C

Physical

Package / Case 0302 (0806 Metric), 6 Lead
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
