CM08RB01
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters COMMON MODE CHK COIL RB TYP
PDF
/
Inventory: 5366
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~105°C
Packaging Bulk
Published 2013
Series CM08
Size / Dimension 0.512Lx0.374W 13.00mmx9.50mm
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Voltage - Rated DC 50V
Shielding Unshielded
Number of Functions 2
Depth 9.5mm
Number of Elements 4
Inductance 40 μH
Test Frequency 30MHz
Impedance 2.5kOhm
Current 2A
Max DC Current 2A
Lead/Base Style Pin
Filter Type Signal Line
Number of Lines 2
DC Resistance (DCR) (Max) 40mOhm
Impedance @ Frequency 2.5kOhm @ 30MHz
Insulation Resistance-Min 100MOhm
Dimensions
Height 14.5mm
Length 13mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
