DSO1-48-0001
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Filters / Common Mode Chokes
Description
Fixed Inductors DSO STORAGE CHOKE 3.15A 1000H
PDF
/
Buying Options
Total Price: USD $71.69
Unit Price: USD $71.685653
≥1 USD $71.685653
≥200 USD $27.741577
≥500 USD $26.767405
≥1000 USD $26.285571
Inventory: 7934
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Terminal Shape WIRE
Weight 195.000012g
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2013
Series DSO
Size / Dimension 1.693Lx0.709W 43.00mmx18.00mm
Tolerance 15%
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
HTS Code 8504.50.80.00
Voltage - Rated DC 600V
Shielding NO
Number of Functions 1
Depth 18mm
Construction Toroidal
Lead Length 40mm
Lead Diameter 0.8 mm
Inductance 1 nH
Max DC Current 3.15A
Inductor Application POWER INDUCTOR
Inductor Type GENERAL PURPOSE INDUCTOR
Number of Lines 2
DC Resistance (DCR) (Max) 180mOhm
Self Resonant Frequency 20MHz
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
