DLNP-6148-01C5
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 1A 2LN TH
PDF
/
Inventory: 6503
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Operating Temperature -40°C~125°C
Self Resonant Frequency 1MHz
DC Resistance (DCR) (Max) 280mOhm
Number of Lines 2
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Inductor Application RF INDUCTOR
Max DC Current 1A
Inductance 50 μH
Lead Length 3.5mm
Lead Pitch 8.75mm
Construction Rectangular
Depth 8.2mm
Number of Functions 1
Shielding NO
Voltage - Rated DC 600V
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 15%
Size / Dimension 0.421Lx0.323W 10.70mmx8.20mm
Series DLNP
Published 2013
Packaging Bulk
Physical
Shape/Size Description RECTANGULAR PACKAGE
Weight 1.000001g
Terminal Shape WIRE
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 23 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 10.5mm
