DKLP-0329-0510
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes DKLP Compensat choke 5A
PDF
/
Buying Options
Total Price: USD $35.75
Unit Price: USD $35.745015
≥1 USD $35.745015
≥200 USD $13.832714
≥500 USD $13.346941
≥1000 USD $13.106681
Inventory: 7354
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 30.8mm
Technical
Self Resonant Frequency 150kHz
DC Resistance (DCR) (Max) 48mOhm
Number of Lines 3
Lead/Base Style Lead Wire
Terminal Placement RADIAL
Inductor Application RF INDUCTOR
Max DC Current 5A
Test Frequency 0.15MHz
Inductance 10 mH
Approval Agency UR
Voltage - Rated AC 540V
Depth 48mm
Number of Functions 3
Shielding NO
Voltage - Rated DC 760V
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Termination Wire
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Size / Dimension 1.890Lx1.890W 48.00mmx48.00mm
Series DKLP-3
Published 2013
Packaging Bulk
Operating Temperature -25°C~100°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Weight 99.988768mg
Terminal Shape FLEXIBLE LEAD
Package / Case Nonstandard
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
