DKIP-0329-1002
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Filters / Common Mode Chokes
Description
Common Mode Chokes / Filters DKIP Compensat choke 10A
PDF
/
Buying Options
Total Price: USD $27.89
Unit Price: USD $27.8872
≥1 USD $27.8872
≥10 USD $23.59984
≥100 USD $20.9726
Inventory: 86
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case Nonstandard
Weight 150.999993g
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -25°C~100°C
Packaging Bulk
Published 2013
Series DKIP-3
Size / Dimension 1.890Lx1.890W 48.00mmx48.00mm
Tolerance 50%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Wire
ECCN Code EAR99
HTS Code 8504.50.80.00
Voltage - Rated DC 760V
Shielding NO
Number of Functions 3
Depth 48mm
Voltage - Rated AC 540V
Approval Agency UR
Inductance 2.5 mH
Max DC Current 10A
Terminal Placement RADIAL
Lead/Base Style Lead Wire
Number of Lines 3
DC Resistance (DCR) (Max) 15mOhm
Self Resonant Frequency 500kHz
Dimensions
Height 30.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
