DKIL-0331-1005

Schurter Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Filters / Common Mode Chokes
Description Common Mode Filters / Chokes DKLP Compensat chke 10A
PDF
/
Inventory: 10039
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 50.8mm

Technical

Self Resonant Frequency 220kHz
DC Resistance (DCR) (Max) 32mOhm
Number of Lines 3
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Max DC Current 10A
Inductance 5 mH
Approval Agency UR
Voltage - Rated AC 540V
Depth 80mm
Number of Functions 3
Shielding NO
Voltage - Rated DC 760V
HTS Code 8504.50.80.00
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
Pbfree Code yes
Tolerance 50%
Size / Dimension 3.150Lx3.150W 80.00mmx80.00mm
Series DKIL-3
Published 2013
Packaging Bulk
Operating Temperature -25°C~100°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Weight 501.219569g
Terminal Shape WIRE
Package / Case Nonstandard
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 15 Weeks
