RN112-1.5/02

Schaffner
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description RADIAL 2 FERRITE RoHS Compliant Common Mode Choke 1.5A 170mOhm 1.7MHz 4.3mH
PDF
/
Inventory: 2329
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Inductance-Nom (L) 3300 μH
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement RADIAL
Inductor Application RF INDUCTOR
Frequency - Self Resonant 1.7MHz
Test Frequency 0.01MHz
Inductance 4.3 mH
Operating Temperature (Max) 125°C
Voltage - Rated AC 250V
Current Rating 1.5A
Reach Compliance Code compliant
Number of Functions 2
Shielding NO
Resistance 170mOhm
Number of Terminations 4
Pbfree Code yes
Tolerance 50%

Physical

Core Material FERRITE
Shape/Size Description RECTANGULAR PACKAGE
Number of Pins 4
Terminal Shape WIRE
Surface Mount NO
