RN212-0.6-02

Schaffner EMC Inc.
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 15mH 10kHz 600mA 465mOhm DCR Thru-Hole
PDF
/
Inventory: 4661
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Height 20.3mm

Technical

Inductance @ Frequency 15mH @ 10kHz
Current Rating (Max) 600mA Typ
Self Resonant Frequency 1kHz
DC Resistance (DCR) (Max) 465mOhm Typ
Number of Lines 2
Series Resistance 465mOhm
DC Current 600mA
Filter Type Power Line
Lead/Base Style Pin
Max DC Current 600mA
Test Frequency 10kHz
Inductance 15 mH
Lead Pitch 15mm
Approval Agency UR, VDE
Voltage - Rated AC 250V
Military Standard Not
Current Rating 600mA
Depth 12.8mm
Shielding Unshielded
Voltage - Rated DC 250V
Resistance 800mOhm
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Pbfree Code yes
Tolerance 50%
Size / Dimension 0.709Lx0.492W 18.00mmx12.50mm
Series RN
Packaging Tray
Operating Temperature -40°C~125°C

Physical

Number of Pins 4
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Radial, Through Hole
