RD8147-25-1M3
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 8 PC Pin
Category Filters / Common Mode Chokes
Description
RD current compensated 4-choke,25A 1.3mH
PDF
/
Buying Options
Total Price: USD $39.05
Unit Price: USD $39.0544
≥1 USD $39.0544
Inventory: 76
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 50.4952mm
Diameter 80mm
Technical
Inductance @ Frequency 1.3mH @ 400Hz
Current Rating (Max) 25A Typ
DC Resistance (DCR) (Max) 5.05mOhm Typ
Number of Lines 4
Filter Type Power Line
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement RADIAL
Inductor Application RF INDUCTOR
Max DC Current 25A
Test Frequency 0.001MHz
Inductance 1.3 mH
Lead Diameter 2.4 mm
Voltage - Rated AC 600V
Number of Functions 4
Shielding NO
Voltage - Rated DC 850V
ECCN Code EAR99
Termination Wire
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance 50%
Size / Dimension 3.150Lx3.150W 80.00mmx80.00mm
Series RD
Published 2011
Packaging Tray
Operating Temperature -25°C~110°C
Physical
Shape/Size Description CYLINDRICAL PACKAGE
Terminal Shape FLEXIBLE LEAD
Package / Case Horizontal, 8 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
