RD7127-36-1M0
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 1mH 1kHz 36A Thru-Hole
PDF
/
Buying Options
Total Price: USD $23.4
Unit Price: USD $23.3992
≥1 USD $23.3992
Inventory: 126
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Horizontal, 4 PC Pin
Terminal Shape FLEXIBLE LEAD
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -25°C~110°C
Packaging Tray
Published 2011
Series RD
Size / Dimension 2.756Lx2.756W 70.00mmx70.00mm
Tolerance 50%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
HTS Code 8504.50.80.00
Voltage - Rated DC 850V
Shielding NO
Number of Functions 2
Depth 70.5mm
Current Rating 36A
Military Standard Not
Voltage - Rated AC 600V
Lead Diameter 2.7 mm
Inductance 1 mH
Test Frequency 1kHz
Element Configuration Dual
Max DC Current 36A
Inductor Application RF INDUCTOR
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
Filter Type Power Line
DC Current 36A
Number of Lines 2
DC Resistance (DCR) (Max) 3.3mOhm Typ
Current Rating (Max) 36A Typ
Inductance @ Frequency 1mH @ 1kHz
Dimensions
Diameter 70mm
Height 40mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
