PL8203T
RoHS
/
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Ind Common Mode Wirewound 530uH 35% 7.2A T/R
PDF
/
Buying Options
Total Price: USD $14.8
Unit Price: USD $14.800322
≥1 USD $14.800322
≥200 USD $5.905424
≥500 USD $5.708489
≥1000 USD $5.611335
Inventory: 7756
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Technical
Operating Temperature -55°C~130°C
Packaging Tape & Reel (TR)
Published 2008
Series SLIC
Size / Dimension 1.110Lx1.000W 28.19mmx25.40mm
Tolerance 35%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Depth 25.4mm
Inductance 530 μH
Max DC Current 7.2A
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 15mOhm
Current Rating (Max) 7.2A
Dimensions
Height 10.03mm
Height (Max) 0.395 10.04mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
