PL8200
RoHS
/
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 470uH 14A 8mOhm DCR SMD Tube
PDF
/
Buying Options
Total Price: USD $10.01
Unit Price: USD $10.0144
≥1 USD $10.0144
≥10 USD $9.53099
≥100 USD $9.36936
≥500 USD $9.04625
≥1000 USD $8.593913
Inventory: 953
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height (Max) 0.500 12.70mm
Length 30.99mm
Height 12.7mm
Technical
Current Rating (Max) 14A
DC Resistance (DCR) (Max) 8mOhm
Number of Lines 2
DC Current 14A
Filter Type Power Line
Max DC Current 14A
Inductance 470 μH
Military Standard Not
Depth 25.4mm
Min Operating Temperature -55°C
Max Operating Temperature 130°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 35%
Size / Dimension 1.220Lx1.000W 30.99mmx25.40mm
Published 2008
Packaging Tube
Operating Temperature -55°C~130°C
Physical
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
