PE-53912NLT image
Favorite
PE-53912NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 1.8mH 2.5A 80mOhm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $2.58
Unit Price: USD $2.5784
≥1 USD $2.5784
≥10 USD $2.18944
≥100 USD $2.017664
≥500 USD $1.802944
≥1000 USD $1.502512
Inventory: 1302
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Radial, Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4

Technical

Operating Temperature -40°C~130°C
Packaging Tape & Reel (TR)
Published 2007
Size / Dimension 0.770Lx0.670W 19.56mmx17.02mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
Voltage - Rated DC 250V
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 2
Depth 17.02mm
Current Rating 2.5A
Military Standard Not
Lead Pitch 16.76mm
Inductance 1.8 mH
Current 2.5A
Max DC Current 2.5A
Filter Type Power Line
DC Current 2.5A
Number of Lines 2
DC Resistance (DCR) (Max) 80mOhm
Self Resonant Frequency 2.2MHz

Dimensions

Height 9.9mm
Length 19.56mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
