PA4339.101NLT image
Favorite
PA4339.101NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description COMMON MODE CHOKE 1.8UH 9A
PDF
/
Buying Options
Total Price: USD $1.56
Unit Price: USD $1.5576
≥1 USD $1.5576
≥10 USD $1.32616
≥100 USD $1.221792
≥500 USD $1.091904
≥1000 USD $0.90992
≥3000 USD $0.883907
Inventory: 4705
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height (Max) 0.150 3.80mm

Technical

Inductance @ Frequency 1.8μH @ 100kHz
Impedance @ Frequency 140Ohm @ 100MHz
Current Rating (Max) 9A
DC Resistance (DCR) (Max) 10mOhm
Number of Lines 2
Filter Type DATA LINE FILTER
Voltage - Rated DC 80V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.276Lx0.236W 7.00mmx6.00mm
Series PA4339
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
