P0502NLT
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 470uH 14A 8mOhm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.368
≥1 USD $5.368
≥10 USD $4.34632
≥100 USD $3.863552
Inventory: 1198
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 30.99mm
Height 12.7mm
Technical
DC Resistance (DCR) (Max) 8mOhm
Number of Lines 2
DC Current 14A
Inductance Tolerance 35%
Filter Type Power Line
Max DC Current 14A
Current 14A
Inductance 470 μH
Military Standard Not
Current Rating 14A
Depth 25.4mm
Number of Functions 2
Shielding Unshielded
Packing Method TR
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 35%
Size / Dimension 1.220Lx1.000W 30.99mmx25.40mm
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~120°C
Physical
Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
