FE2X27-3-3NL
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Current Transformer 1500VAC 1.7Ohm Prim. DCR 27000uH Prim. 400mA Prim. 4Term. PC Pin Thru-Hole
PDF
/
Buying Options
Total Price: USD $2.26
Unit Price: USD $2.256095
≥1 USD $2.256095
≥10 USD $2.128391
≥100 USD $2.00791
≥500 USD $1.894264
≥1000 USD $1.787042
Inventory: 1478
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 12.9032mm
Technical
DC Resistance (DCR) (Max) 1.7Ohm
Number of Lines 2
Filter Type DATA LINE FILTER
Lead/Base Style PC Pin
Current 400mA
Inductance 27 mH
Voltage - Rated AC 250V
Depth 17.9mm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.705Lx0.705W 17.91mmx17.91mm
Series FE2X
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 4
Package / Case Horizontal, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 11 Weeks
