TM8116NLT
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
470μH @ 100kHz 2 Line Common Mode Choke Surface Mount 800 Ohm @ 100MHzDCR 300 mOhm
PDF
/
Inventory: 7788
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status RoHS Compliant
Dimensions
Height 4.0894mm
Technical
Inductance @ Frequency 470μH @ 100kHz
Transformer Type TELECOM TRANSFORMER
Impedance @ Frequency 800Ohm @ 100MHz
DC Resistance (DCR) (Max) 300mOhm
Number of Lines 2
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.350Lx0.248W 8.90mmx6.30mm
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
