T8114NL
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 400MA 2LN SMD
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 6528
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 6.3mm
Length 6.6mm
Height 4.0894mm
Technical
Rated Voltage 80V
DC Resistance (DCR) (Max) 700mOhm
Number of Lines 2
Filter Type Signal Line
Lead/Base Style Gull Wing
Current 400mA
Inductance 4.7 mH
Number of Functions 2
Packing Method TAPE AND REEL
Additional Feature COMMON MODE CHOKE
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.350Lx0.248W 8.90mmx6.30mm
Published 2006
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 4
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount, Through Hole
Supply Chain
Factory Lead Time 9 Weeks
