R0003NLT
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 6 Flat Lead
Category Filters / Common Mode Chokes
Description
Surface Mount Common Mode Chokes
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.596
≥1 USD $2.596
≥10 USD $2.1692
≥100 USD $1.980704
≥500 USD $1.697696
≥1000 USD $1.55628
≥3000 USD $1.509094
Inventory: 847
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height (Max) 0.098 2.50mm
Width 6.604mm
Length 8.636mm
Height 2.4892mm
Technical
DC Resistance (DCR) (Max) 400mOhm
Number of Lines 3
Filter Type Signal Line
Inductance 20 μH
Depth 8.64mm
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.340Lx0.260W 8.64mmx6.60mm
Published 2004
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case Vertical, 6 Flat Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
