PE-69011NLT
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 16 Gull Wing
Category Filters / Common Mode Chokes
Description
Surface Mount Common Mode Chokes
PDF
/
Buying Options
Total Price: USD $6.21
Unit Price: USD $6.2128
≥1 USD $6.2128
≥10 USD $5.11192
≥100 USD $4.697088
≥500 USD $4.420768
≥1000 USD $4.213616
≥3000 USD $4.144518
Inventory: 2141
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height (Max) 0.200 5.08mm
Width 6.985mm
Length 12.7mm
Height 5.08mm
Technical
DC Resistance (DCR) (Max) 350mOhm
Number of Lines 8
Filter Type Signal Line
Lead/Base Style Gull Wing
Inductance 36 μH
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Size / Dimension 0.500Lx0.275W 12.70mmx6.99mm
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 16
Package / Case Vertical, 16 Gull Wing
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
