H6505NL image
Favorite
H6505NL image
Favorite
RoHS
RoHS RoHS compliant
Package Vertical, 8 Gull Wing
Category Filters / Common Mode Chokes
Description COMMON MODE CHOKE 4LN SMD
PDF
/
Inventory: 2535
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Vertical, 8 Gull Wing

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Published 2008
Size / Dimension 0.245Lx0.365W 6.22mmx9.27mm
Tolerance 35%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Packing Method TAPE AND REEL
Number of Functions 2
Depth 9.27mm
Inductance 500 μH
Filter Type DATA LINE FILTER
Number of Lines 4
DC Resistance (DCR) (Max) 280mOhm

Dimensions

Height 5.588mm
Length 6.6mm
Width 6.22mm

Compliance

RoHS Status RoHS Compliant
