B2013T
RoHS
/
Package Vertical, 8 Gull Wing
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 6.3mH 29dB 100MHz SMD T/R
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 5900
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case Vertical, 8 Gull Wing
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Published 2006
Size / Dimension 0.566Lx0.475W 14.37mmx12.07mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Additional Feature COMMON MODE CHOKE
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 2
Depth 15.24mm
Inductance 9 mH
Test Frequency 100MHz
Element Configuration Dual
Filter Type Signal Line
Number of Lines 2
DC Resistance (DCR) (Max) 1Ohm
Current Rating (Max) 100mA
Inductance @ Frequency 9mH @ 100kHz
Dimensions
Height 8.64mm
Compliance
RoHS Status Non-RoHS Compliant
