B2006 image
Favorite
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description Telecom Transformer 1:1/1:1 1500Vrms 0.8Ohm Prim. DCR 0.8Ohm Sec. DCR 3dB Through Hole
PDF
/
Inventory: 9544
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole

Technical

Packaging Bulk
Published 2012
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
Packing Method TRAY
Approval Agency UL; BABT
Operating Temperature (Max) 85°C
Physical Dimension 26.67mm X 24.13mm X 12.7mm
Operating Temperature (Min) -40°C
DC Resistance (DCR) 800mOhm
Lead/Base Style PC Pin
Isolation Voltage 1.5kV
Transformer Type TELECOM TRANSFORMER
Turns Ratio - Primary:Secondary 1:1

Dimensions

Height 12.7mm
Length 26.67mm
Width 24.13mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
