EXC-24CB221U
RoHS
RoHS compliant
RoHS compliantPackage 0504 (1210 Metric), 4 Lead
Category Filters / Common Mode Chokes
Description
CMC 100MA 2LN 220 OHM SMD
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.38896
≥100 USD $0.356576
≥500 USD $0.324192
≥1000 USD $0.288552
≥3000 USD $0.272378
Inventory: 1278
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0504 (1210 Metric), 4 Lead
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2011
Series EXC24
Size / Dimension 0.049Lx0.039W 1.25mmx1.00mm
Tolerance 25%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Additional Feature COUPLED TYPE; HIGH SPEED SIGNAL TYPE
HTS Code 8504.50.80.00
Voltage - Rated DC 5V
Packing Method TAPE AND REEL
Shielding Shielded
Number of Functions 2
Depth 1.15mm
Frequency 100MHz
Case Code (Metric) 1210
Case Code (Imperial) 0504
Test Frequency 100MHz
Impedance 220Ohm
Current 100mA
Max DC Current 100mA
Filter Type Signal Line
DC Current 100mA
Number of Lines 2
DC Resistance (DCR) (Max) 700mOhm
Impedance @ Frequency 220Ohm @ 100MHz
Rated Voltage 5V
Dimensions
Height 500μm
Width 1mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
