EXC-18CE900U
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Filters / Common Mode Chokes
Description
CMC 130MA 4LN 90 OHM SMD
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.215591
≥1 USD $0.215591
≥200 USD $0.083435
≥500 USD $0.080507
≥1000 USD $0.07905
Inventory: 6091
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 1.6mm
Height 508μm
Technical
Rated Voltage 5V
Impedance @ Frequency 90Ohm @ 100MHz
DC Resistance (DCR) (Max) 2Ohm
Number of Lines 4
Rated Current 0.13A
Filter Type Signal Line
Max DC Current 130mA
Impedance 90Ohm
Test Frequency 100MHz
Frequency 100MHz
Depth 900μm
Number of Functions 4
Packing Method TAPE AND REEL
Voltage - Rated DC 5V
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 20%
Size / Dimension 0.063Lx0.031W 1.60mmx0.80mm
Series EXC18
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
